Signal Generator J3B

• Country
• Great Britain (UK)

• Manufacturer / Brand
• Gould Advance Ltd.; Hainault

• Year
• 1990 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 173390

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 85-130 / 170-225 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Signal Generator J3B - Gould Advance Ltd.; Hainault

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 270 x 135 x 270 mm / 10.6 x 5.3 x 10.6 inch

• Notes
• Signal Generator giving both Sinewave and Squarewave outputs. Low Distortion Output 0V to 2.5 V; Z=5 KOhm. Power supply AC 85 - 130V / 170 - 225V at 40 - 400Hz. Input for external DC power supply 40 - 48 V.

• Source of data
• - - Data from my own collection
