• Country
• Brazil

• Manufacturer / Brand
• Gradiente Eletrônica S.A.; São Paulo

• Year
• 1995 ??

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 273604

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 100-140 / 200-280 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Stereo Control Amplifier P-II - Gradiente Eletrônica S.A.; São

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 452 x 94 x 262 mm / 17.8 x 3.7 x 10.3 inch

• Notes

• Gradiente Stereo Control AMplifier Model P-II (P-2).
  Bass- & Treble Control
  Infrasonic Filter  -3dB 14Hz (12dB/Oct)
  Ultrasonic Filter -3dB 26000Hz (12dB/Oct)
  Mute
  Loudness (+8dB 50Hz, +5dB 10000Hz)
  Inputs:
  Phono MM, Phono MC, DAD, Tape, Tuner, Tape 1, Tape2, AUX
  AC Outlets:
  2x Switched, 2x Unswitched
  Power Consumption 20 Watts.


• Net weight (2.2 lb = 1 kg)
• 5.2 kg / 11 lb 7.3 oz (11.454 lb)

• Mentioned in
• - - Manufacturers Literature (Instruction Manual)

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
