Belcanto 8 1223 dunkel poliert
Graetz, Altena (Westfalen)
- Country
- Germany
- Manufacturer / Brand
- Graetz, Altena (Westfalen)
- Year
- 1963/1964
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 24832
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superheterodyne (common); ZF/IF 460/10700 kHz
- Tuned circuits
- 6 AM circuit(s) 10 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 150; 220; 240 Volt
- Loudspeaker
- 4 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Belcanto 8 1223 [dunkel poliert] - Graetz, Altena Westfalen
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 1415 x 725 x 375 mm / 55.7 x 28.5 x 14.8 inch
- Notes
- Rundfunk-Chassis = Truhenbausteine 1224HF (Stereo-Decoder 1269 nachrüstbar) und 1225NF; NF-Verstärker mit 2 Endstufen je 7,5 W; Phono-Chassis = Perpetuum-Ebner PE66.
- Net weight (2.2 lb = 1 kg)
- 60 kg / 132 lb 2.5 oz (132.159 lb)
- Price in first year of sale
- 1,199.00 DM
- External source of data
- Erb
- Source of data
- Handbuch VDRG 1963/1964
