• Country
• Germany

• Manufacturer / Brand
• Graetz, Altena (Westfalen)

• Year
• 1974/1975

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 160349

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 9

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz

• Tuned circuits
• 5 AM circuit(s)     7 FM circuit(s)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 1 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Form 99 - Graetz, Altena Westfalen

• Shape
• Tablemodel with Clock ((Alarm-) Clock Radio).

• Dimensions (WHD)
• 165 x 155 x 190 mm / 6.5 x 6.1 x 7.5 inch

• Notes
• Uhrenradio mit digitaler Klappziffer-Anzeige (Uhrwerk Copal, Japan). Form etwa wie liegendes "U". 12 Dioden und Gleichrichter. Anschluß für Außenlautsprecher/Ohrhörer. Ausführung: Kunststoff, weiß oder rot. 24 Stunden-Anzeige. Verkauf über die Weltfunk anlässlich der Funkausstellung 1975

• Net weight (2.2 lb = 1 kg)
• 1.7 kg / 3 lb 11.9 oz (3.744 lb)

• Price in first year of sale
• 179.00 DM

• Source of data
• Handbuch VDRG 1974/1975

• Mentioned in
• Taxliste Franzis Verlag

• Author
• Model page created by Boris Witke † 9.2024. See "Data change" for further contributors.
