• Country
• Germany

• Manufacturer / Brand
• Graetz, Altena (Westfalen)

• Year
• 1972 ??

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 84216

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• PL504 PCF802 PCL805 PL95 PY88 A61-120W/2

• Number of Transistors
• 37

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: Gouverneur electronic 2355 - Graetz, Altena Westfalen

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 720 x 480 x 415 mm / 28.3 x 18.9 x 16.3 inch

• Notes
• 1 IC, 46 Dioden, 4 Gleichrichter
  Empfangsbereiche: VHF I, VHF III, UHF IV/V.
  Fernbedienung Typ FB1200 electronic, 5652 02 03.

• Net weight (2.2 lb = 1 kg)
• 25.3 kg / 55 lb 11.6 oz (55.727 lb)

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by a member from D. See "Data change" for further contributors.
