Kalif F23 Ch= 3441
Graetz, Altena (Westfalen)
- Country
- Germany
- Manufacturer / Brand
- Graetz, Altena (Westfalen)
- Year
- 1955/1956
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 20131
ebay: surfguru
ebay: surfguru
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 20
- Valves / Tubes
- PCC84 PCF80 EBF80 EF80 EF80 EF80 EF80 PL83 EF80 EH90 ECC82 PCL82 ECC82 PL36 PY81 EY86 EBF80 EF89 PL82 MW53-80
- Main principle
- Superheterodyne (common)
- Power type and voltage
- AC/DC-set / 220 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Kalif F23 Ch= 3441 - Graetz, Altena Westfalen
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 700 x 953 x 549 mm / 27.6 x 37.5 x 21.6 inch
- Notes
- Dioden: OA160, 2× OA161, 2× OA172
- Net weight (2.2 lb = 1 kg)
- 55 kg / 121 lb 2.3 oz (121.145 lb)
- Price in first year of sale
- 1,398.00 DM
- External source of data
- Erb
- Source of data
- HdB d.Rdf-& Ferns-GrH 1955/56
- Literature/Schematics (1)
- -- Original-techn. papers. (Reparaturdienst-Liste)
