Mandarin electronic 2380
Graetz, Altena (Westfalen)
- Country
- Germany
- Manufacturer / Brand
- Graetz, Altena (Westfalen)
- Year
- 1972 ??
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 84214
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Number of Transistors
- 37
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Details
- Remote Control (with wire or wireless)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Wooden case
- from Radiomuseum.org
- Model: Mandarin electronic 2380 - Graetz, Altena Westfalen
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 820 x 920 x 420 mm / 32.3 x 36.2 x 16.5 inch
- Notes
- 1 IC, 46 Dioden, 4 Gleichrichter
Empfangsbereiche: VHF I, VHF III, UHF IV/V.
Fernbedienung Typ FB1200 electronic, 5652 02 03.
- Net weight (2.2 lb = 1 kg)
- 42.5 kg / 93 lb 9.8 oz (93.612 lb)
