• Country
• Germany

• Manufacturer / Brand
• Graetz, Altena (Westfalen)

• Year
• 1955/1956

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 20129

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 20

• Valves / Tubes
• PCC84 PCF80 EBF80 EF80 EF80 EF80 EF80 PL83 EF80 EH90 ECC82 PCL82 ECC82 PL81 PY81 EY86 EBF80 EF89 PL82 MW43-64

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• AC/DC-set / 220 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Mandarin F20 Ch= 3429 - Graetz, Altena Westfalen

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 540 x 900 x 550 mm / 21.3 x 35.4 x 21.7 inch

• Notes
• Dioden: 2× OA161, 2× OA172. 12 Kanäle im VHF-bereich.

• Net weight (2.2 lb = 1 kg)
• 41 kg / 90 lb 4.9 oz (90.308 lb)

• Price in first year of sale
• 998.00 DM

• External source of data
• Erb

• Source of data
• HdB d.Rdf-& Ferns-GrH 1955/56

• Literature/Schematics (1)
• -- Original-techn. papers. (Reparaturdienst-Liste)
