Scerzo 7 1318L Nussbaum
Graetz, Altena (Westfalen)
- Country
- Germany
- Manufacturer / Brand
- Graetz, Altena (Westfalen)
- Year
- 1964/1965
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 25754
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superheterodyne (common)
- Tuned circuits
- 6 AM circuit(s) 10 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 150; 220; 240 Volt
- Loudspeaker
- 4 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Scerzo 7 1318L [Nussbaum] - Graetz, Altena Westfalen
- Shape
- Console with Push Buttons.
- Dimensions (WHD)
- 1160 x 780 x 370 mm / 45.7 x 30.7 x 14.6 inch
- Notes
- Rundfunk-Chassis = 1318L; Stereo-NF-Verstärker mit 2 Endstufen je 10 W;
Phono-Chassis = Perpetuum-Ebner PE66.
Im VDRG-Handbuch sind fälschlicherweise nur 2 Breitband-Lautsprecher angegeben.
- Net weight (2.2 lb = 1 kg)
- 35 kg / 77 lb 1.5 oz (77.093 lb)
- Price in first year of sale
- 1,180.00 DM
- External source of data
- Erb
- Source of data
- Handbuch VDRG 1964/1965
- Literature/Schematics (1)
- -- Original-techn. papers.
