• Year
  • 1956 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 281503

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 7
  • Main principle
  • Superhet with RF-stage; ZF/IF 455/10700 kHz
  • Tuned circuits
  • 6 AM circuit(s)     9 FM circuit(s)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • AC/DC-set / 105-120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Material
  • Bakelite or Plastics (type unknown)
  • from Radiomuseum.org
  • Model: 740P - Granco Products, Inc.; Long
  • Shape
  • Tablemodel, with any shape - general.
  • Notes
  • AC-DC Operated FM-AM Superheterodyne Receiver. Speaker : 5x7 inch.




  • Author
  • Model page created by Dirk Taekels. See "Data change" for further contributors.
