CR-8

• Country
• United States of America (USA)

• Manufacturer / Brand
• Grebe, A.H. & Co.; Richmond Hill (NY)

• Year
• 1921

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 43519

• • Brand: Synchrophase

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• C300

• Main principle
• TRF with regeneration

• Tuned circuits
• 2 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Storage and/or dry batteries / 6 & 22.5 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Wooden case

• from Radiomuseum.org
• Model: CR-8 - Grebe, A.H. & Co.; Richmond

• Shape
• Tablemodel, Box - most often with Lid (NOT slant panel).

• Notes
• Wave length 150 to 1000 meters.
  In 1923 the C299 was also recommended for dry battery operation.

• Price in first year of sale
• 80.00 $

• External source of data
• Ernst Erb

• Source of data
• Radio Collector`s Guide 1921-1932

• Circuit diagram reference
• Rider's Perpetual, Volume 1 = 1931/1934 (for 1919-1931)

• Mentioned in
• Collector's Guide to Antique Radios 4. Edition (Andrae Catalog R-6 (1923))

• Literature/Schematics (1)
• Radio Manufacturers of the 1920's, Vol. 2

• Literature/Schematics (2)
• Radio Broadcast, Jun. 1922, p. 182

• Literature/Schematics (3)
• Radio Digest Illustrated, 1922 May 13, p. 5
