AM-FM Stereo Radio Cassette Recorder RR 370K

Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

Data
Forum
Pictures
Collections

  • Year
  • 1989 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 259595
    • alternative name: Grundig Portugal || Grundig USA / Lextronix

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 460/10700 kHz
  • Wave bands
  • Broadcast, Short Wave plus FM or UHF.
  • Details
  • Cassette-Recorder or -Player; Radio with other functions
  • Power type and voltage
  • Line / Batteries (any type) / 220-230 / D: 6 x 1,5 Volt
  • Loudspeaker
  • 2 Loudspeakers / Ø 10 cm = 3.9 inch
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: AM-FM Stereo Radio Cassette Recorder RR 370K - Grundig Radio-Vertrieb, RVF,
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 430 x 165 x 125 mm / 16.9 x 6.5 x 4.9 inch
  • Notes

  • Auto-Reverse, one touch Recording; Automatic Stop; Condenser Microphone; UBS (Ultra Bass System).

    The  running direction of the tape can be changed by the Auto Reverse System, but also  manually via a switch on the right side .

    There are two versions of the RR 370 :

    One with the wavebands FM, MW and LW,one with the wavebands FM, MW and SW (RR 370 K )

  • Net weight (2.2 lb = 1 kg)
  • 2.2 kg / 4 lb 13.5 oz (4.846 lb)
  • Author
  • Model page created by Museum Roggenhofer. See "Data change" for further contributors.

 Collections | Museums | Literature

Collections

The model AM-FM Stereo Radio Cassette Recorder is part of the collections of the following members.

 Forum

Forum contributions about this model: Grundig Radio-: AM-FM Stereo Radio Cassette Recorder RR 370K

Threads: 1 | Posts: 2

Dies ist ein sehr interessantes Gerät. Statt des " Auto Stops " hat es " Auto Reserve ".Wenn also die Kassette zu Ende kommt, wird sie nicht  automatisch abgeschaltet, sondern umgehend weiter gefahren.

Interessant ist  auch, daß nicht nur jeweils am Ende der Kassette der Weg umgedreht wird. Den Umweg kann man auch mit einer Taste andrücken.









Ottmar Lauth, 08.Dec.19
