- Country
- Germany
- Manufacturer / Brand
- Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Year
- 1981
- Category
- Loudspeaker, headphone or earphone
- Radiomuseum.org ID
- 218579
-
- alternative name: Grundig Portugal || Grundig USA / Lextronix
- Wave bands
- - without
- Details
- Hi-Fi equipment
- Power type and voltage
- No Power needed
- Loudspeaker
- 3 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Box 860 - Grundig Radio-Vertrieb, RVF,
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 280 x 460 x 250 mm / 11 x 18.1 x 9.8 inch
- Notes
-
Grundig 3-Weg Compact-Box Model 860.
Übertragungsbereich 31,5 - 25000 Hz
Impedanz: 4 Ohm;
Spitzenleistung: 100 Watt
Dauerton-Leistung: 70 Watt
Chassis:
Bass-Lautsprecher: 19 cm
Mittelton-Kalotte: 11x11 cm
Hochton-Kalotte: 11x9 cm;
Übergangsfrequenzen: 1 kHz und 3,15 kHz
Netto-Volumen 20,7 Liter
Gehäuseausführung:
Nussbaumfarben, Metallic, Braun
- Net weight (2.2 lb = 1 kg)
- 10.5 kg / 23 lb 2 oz (23.128 lb)
- Mentioned in
- -- Original prospect or advert (Grundig Lautsprecherprogramm 1981/82)
- Author
- Model page created by Hans-Werner Ellerbrock. See "Data change" for further contributors.
