Fernseh-Boy P1201
Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Country
- Germany
- Manufacturer / Brand
- Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Year
- 1968/1969
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 240506
-
- alternative name: Grundig Portugal || Grundig USA / Lextronix
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 3
- Number of Transistors
- 13
- Semiconductors
- BF121 BF225 BF224 BF224 BC183 or. BC168 BC183 or. BC168 BC213 BC213 BC213 BC182 BC182 BF117 unknown_tr unknown_IC M40C4 TV13 OA90 OA90 1N4004 B0580
- Main principle
- Superheterodyne (common)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 1 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Fernseh-Boy P1201 - Grundig Radio-Vertrieb, RVF,
- Shape
- Tablemodel with Push Buttons.
- Notes
-
Allbereich-Tuner für VHF und UHF, 8 Stationsspeicher über Monomat.
Intercarrier-Tonteil mit separater Diode zur Erzeugung der 5,5 MHz Differenzfrequenz.
- Mentioned in
- -- Schematic (Il Video Libro, D.E. Ravalico, VII edizione - Hoepli.)
- Literature/Schematics (1)
- Grundig Service Unterlagen
- Author
- Model page created by Josef Pilz. See "Data change" for further contributors.
