• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

• Year
• 1991–1993

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 228496

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 230 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 560 W (720 W max.)

• Material
• Various materials

• from Radiomuseum.org
• Model: Fine Arts High Definition Stereo Integrated Amplifier A-9009 - Grundig Radio-Vertrieb, RVF,

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 435 x 146 x 334 mm / 17.1 x 5.7 x 13.1 inch

• Notes

• Fine Arts Classic Stereo-Amplifier A-9009, Ausgangsleistung 2 x 360/280 Watt Musik-/Sinus an 4Ω, Fernbedienung ( RC 9009 ), Anschlüsse für 2 LS-Gruppen, Gehäuse Schwarz.

  • Dauerleistung (nach DIN 45 500)
    • 8 Ohm: 2 x 180 W
    • 4 Ohm: 2 x 280 W
  • Dynamikleistung
    • 8 Ohm: 2 x 240 W
    • 4 Ohm: 2 x 360 W
  • Gesamtklirrfaktor: 0,005% (Nennleistung, 1 kHz)
  • Dämpfungsfaktor: größer 250
  • Frequenzgang: 5 - 100.000 Hz
  • Signalrauschabstand: nach IEC (160 W / 50 mW)Phono MM: 82 / 77 dBPhono MC: 78 / 76 dBHochpegel: 103 / 83 dB
  • Stereokanaltrennung: größer 77db
  • Klangregelung:
    • Bass: ja
    • Höhen: ja
  • Loudness: ja
  • High Filter: nein
  • Low Filter (Subsonic): ja, 15 Hz (6 dB/oct)
  • Mute: ja
  • Direct/Line-Straight: ja

• Net weight (2.2 lb = 1 kg)
• 17.5 kg / 38 lb 8.7 oz (38.546 lb)

• Price in first year of sale
• 2,200.00 DM

• Source of data
• -- Original prospect or advert

• Author
• Model page created by Karlheinz Fischer. See "Data change" for further contributors.
