• Year
  • 1964/1965
  • Category
  • Microphone or Pick-up element
  • Radiomuseum.org ID
  • 71710
    • alternative name: Grundig Portugal || Grundig USA / Lextronix

 Technical Specifications

  • Power type and voltage
  • No Power needed
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: GDM310 - Grundig Radio-Vertrieb, RVF,
  • Dimensions (WHD)
  • 35 x 35 x 78 mm / 1.4 x 1.4 x 3.1 inch
  • Notes
  • Dynamisches Mikrofon, Kugelcharakteristik. Übertragungsbereich 100 - 15.000 Hz. Empfindlichkeit 1,5 mV/Pa, Impedanz 200 Ohm. Festes Anschlußkabel mit 3-pol. DIN-Stecker. Mit Tischständer.
  • Net weight (2.2 lb = 1 kg)
  • 0.1 kg / 0 lb 3.5 oz (0.22 lb)
  • Price in first year of sale
  • 32.00 DM
  • External source of data
  • Grundig Datentabelle f. Mikrofone 11/1964
  • Mentioned in
  • -- Original-techn. papers.
  • Author
  • Model page created by Hilmer Grunert. See "Data change" for further contributors.
