HiFi-Mini-Receiver MR100 (GB, U)

• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

• Year
• 1980/1981

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 173271

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: HiFi-Mini-Receiver MR100 - Grundig Radio-Vertrieb, RVF,

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 270 x 110 x 200 mm / 10.6 x 4.3 x 7.9 inch

• Notes
• 3 Ausführungen: MR100, MR100GB und MR100U
  Grundig HiFi-Mini-Receiver MR100,
  UKW/MW/LW, Feinabstimmungsanzeige, MPX, Linear-Taste,
  Höhen/Tiefen/Balanceregler, 2x TAPE/PHONO-Anschlüsse,
  zwei Lautsprecheranschlüsse, 2x 35 Watt Musikleistung,
  Anschlüsse für 2 Tonband Cassetten-Geräte mit gegenseitiger Überspielmöglichkeit,
  1-Volt-Ausgang zum Ansteuern von Aktiv-Boxen oder Endverstärkern.

• Net weight (2.2 lb = 1 kg)
• 6.5 kg / 14 lb 5.1 oz (14.317 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Karlheinz Fischer. See "Data change" for further contributors.
