TK600 HiFi-Stereo

• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

• Year
• 1970–1972

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 28130

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 35

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 110; 117; 127; 160; 220; 240 Volt

• Loudspeaker
• 4 Loudspeakers

• from Radiomuseum.org
• Model: TK600 HiFi-Stereo - Grundig Radio-Vertrieb, RVF,

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 420 x 190 x 370 mm / 16.5 x 7.5 x 14.6 inch

• Notes
• Grundig Tonbandkoffer TK600 HiFi-Stereo.
  Vierspur-Stereo; Bandgeschwindigkeiten: 9,5/19 cm/s; Spulen-Ø: 18 cm; Übertragungsbereich bei 19 cm/s: 30···18000 Hz. Stereo-NF-Verstärker mit 2 Endstufen je 10 W.

• Net weight (2.2 lb = 1 kg)
• 13.8 kg / 30 lb 6.3 oz (30.396 lb)

• External source of data
• Erb

• Source of data
• Handbuch VDRG 1970/1971
