TK745 HiFi-Stereo

• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

• Year
• 1973–1976

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 29203

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 34

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• 2 Loudspeakers

• Power out
• 14 W (unknown quality)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: TK745 HiFi-Stereo - Grundig Radio-Vertrieb, RVF,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 500 x 150 x 310 mm / 19.7 x 5.9 x 12.2 inch

• Notes
• Grundig Hi-Fi-Stereo-Tonbandkoffer TK745 HiFi-Stereo.
  Vierspur-HiFi-Stereo; Bandgeschwindigkeiten: 4,75 / 9,5 / 19 cm/s; Spulen-Ø: 18 cm; Übertragungsbereich bei 19 cm/s: 30-18000 Hz; Ausgangsleistung: 2× 7 W;
  Waagerecht- und Senkrecht-Betrieb.
  Trickmöglichkeiten: Synchroplay, Multiplay, Duoplay, Echo.

• Net weight (2.2 lb = 1 kg)
• 12 kg / 26 lb 6.9 oz (26.432 lb)

• Price in first year of sale
• 620.00 DM

• External source of data
• Erb

• Source of data
• Katalog RFP 1973

• Mentioned in
• Handbuch VDRG 1974/1975 (und 1975/76)
