HiFi-System R 220

Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

Data
Forum
Pictures
Collections

  • Year
  • 1994 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 231071
    • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • PLL, Phase-locked loop; ZF/IF 455/10700 kHz
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Details
  • Other Combination - see Notes; Hi-Fi equipment
  • Power type and voltage
  • Alternating Current supply (AC) / 230 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 100 W (190 W max.)
  • from Radiomuseum.org
  • Model: HiFi-System R 220 - Grundig Radio-Vertrieb, RVF,
  • Shape
  • Book-shelf unit.
  • Notes

  • HiFi-Stereo System mit folgenden Bausteinen: R 220 Receiver, CD 120 CD-Spieler, CCF 120 Cassetten Doppeldeck, R 220-RC Fernsteuerung.

  • Source of data
  • -- Original-techn. papers.
  • Author
  • Model page created by a member from D. See "Data change" for further contributors.
