• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

• Year
• 1966/1967

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 118413

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• ECC85 ECH81 EAF801 ECC83 EM87 ECLL800 ECLL800

• Number of Transistors

• Semiconductors
• B250C135 AA113 AA113

• Main principle
• Superheterodyne (common); Export model

• Tuned circuits
• 7 AM circuit(s)     10 FM circuit(s)

• Wave bands
• Broadcast, 2 Short Wave plus FM or UHF.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 115 Volt

• Loudspeaker
• 7 or more Loudspeakers

• Power out
• 7.5 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Stereo Console KS760U Ch= HF45U - Grundig Radio-Vertrieb, RVF,

• Shape
• Console with Push Buttons.

• Dimensions (WHD)
• 60 x 33 x 17 inch / 1524 x 838 x 432 mm

• Notes

• US export model with 8 permanent-dynamic speakers and 2 electrostatic tweeters.

  Receiver chassis = HF45U
  Record changer: Dual 1010

  For FM stereo reception a Stereo Decoder 6U needs to be fitted (optional).
