Majestic 5088 USA

Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

Data
Forum
Pictures
Collections

  • Year
  • 1957 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 145870
    • alternative name: Grundig Portugal || Grundig USA / Lextronix

 Technical Specifications

  • Number of Tubes
  • 8
  • Main principle
  • Superheterodyne (common); Export model
  • Tuned circuits
  • 13 FM circuit(s)
  • Wave bands
  • Broadcast, 2 Short Wave plus FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 110-220 Volt
  • Loudspeaker
  • 4 Loudspeakers
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Majestic 5088 USA - Grundig Radio-Vertrieb, RVF,
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 670 x 400 x 290 mm / 26.4 x 15.7 x 11.4 inch
  • Notes
  • Grundig Majestic 5088 USA;
    US export model with AM-MW, SW1: ~3.2 - 8 MHz, SW2: 8.5 - 18 MHz, FM: 88 - 108 MHz, magic eye - tuning indicator tube, english labeled, 4 controls multisonic sound equalizer as well as 3 button sound program selector, muting button, internal or ext. antenna in, front controlled turnable ferrite antenna bar, phono in, DIN terminal (Deutsche Industrie Norm) tape in, ext. speaker terminals, 55 W power consumption, made in Germany, sold in US by Grundig Majestic International Chicago Ill. & New York N.Y.
    Compare with an other slightly different export version "Grundig 5088 WE" and the German domestic versions "Grundig Konzertgerät 5088".
  • Mentioned in
  • -- Original prospect or advert
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.

 Collections | Museums | Literature

Collections

The model Majestic is part of the collections of the following members.

 Forum

Forum contributions about this model: Grundig Radio-: Majestic 5088 USA

Threads: 1 | Posts: 3

I'm currently restoring a Grundig Majestic 5088 USA and have the radio working on all bands and it sounds fantastic on FM. So far, so good.

Only problem is that when searching stations on FM the sound (whether it's noise or some FM station) will disappear and come back randomly when turning the tuning knob. Once I'm on a station I often have to wiggle (turn it back and forth a little) the tuning knob a bit to get sound and good reception.

Since the FM tuning capacitor sits on the outside of the FM unit I'm guessing this is caused by dust or other dirt in or on that capacitor.

I already used a vacuum cleaner and a soft brush to clean the thing as best as I could and while that helped a bit it didn't fix it completely.

My question is: what is the best and safest way to clean the FM tuning capacitor? Compressed air or spray it with Deoxit or WD-40 or.. ? What has worked for you?

Thank you in advance for your time.

Ton

Antoni Regeling, 03.Feb.25
