Majestic Black Magic Deluxe
Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Country
- Germany
- Manufacturer / Brand
- Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Year
- 1961 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 232157
-
- alternative name: Grundig Portugal || Grundig USA / Lextronix
- Number of Transistors
- 9
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 460/10700 kHz
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Dry Batteries / D 6 x 1.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 4 inch = 10.2 cm
- Power out
- 0.8 W (unknown quality)
- Material
- Various materials
- from Radiomuseum.org
- Model: Majestic Black Magic Deluxe - Grundig Radio-Vertrieb, RVF,
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 12.5 x 7 x 3.5 inch / 318 x 178 x 89 mm
- Notes
-
Grundig Black Magic deluxe is an export model.
See also the similar domestic radio Transonette 99.
- Net weight (2.2 lb = 1 kg)
- 1.5 lb (1 lb 8 oz) / 0.681 kg
- Author
- Model page created by James Ruggles. See "Data change" for further contributors.
