Monomat SE P1600SE
Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Country
- Germany
- Manufacturer / Brand
- Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Year
- 1967/1968
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 317468
-
- alternative name: Grundig Portugal || Grundig USA / Lextronix
Detailansicht des Monomat SE Tuners
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 9
- Number of Transistors
- 7
- Main principle
- Superhet with RF-stage; ZF/IF 38900/5500 kHz
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Monomat SE P1600SE - Grundig Radio-Vertrieb, RVF,
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 470 x 385 x 290 mm / 18.5 x 15.2 x 11.4 inch
- Notes
-
Einknopf-6-Programm-Schnellwahlautomatik Monomat SE für 6 VHF- oder UHF-Programme, Linearskala für Kanal- und Bereichsanzeige, beleuchtete Programmanzeige.
Siehe auch Grundig Fernseh-Boy Monomat SE P1600SEa
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Museum Stuttgart. See "Data change" for further contributors.
