Multi Editing System (Video-Audio Mixer) VS10

Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

Data
Forum
Pictures
Collections

  • Year
  • 1992 ??
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 272457
    • alternative name: Grundig Portugal || Grundig USA / Lextronix

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Other Combination - see Notes
  • Power type and voltage
  • Powered by external power supply or a main unit. / AC 9 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Multi Editing System VS10 - Grundig Radio-Vertrieb, RVF,
  • Shape
  • Tablemodel, slant panel.
  • Dimensions (WHD)
  • 295 x 50 x 225 mm / 11.6 x 2 x 8.9 inch
  • Notes

  • Grundig VS10 digital gesteuertes Mischpult für analog-Video und Stereo-Ton. Betrieb mit 9-Volt 1,5A-Steckerteil (AC). Programmspeicherkarte: 128 kByte, kann eingesteckt werden. Internes RAM: 32 kByte (statisch). Szenenspeicher und Kommentarspeicher. Videostandards: Y-/C-Video und Composite Video (PAL). Grundig Best.Nr. G-MA 6800 X.

  • Net weight (2.2 lb = 1 kg)
  • 1.2 kg / 2 lb 10.3 oz (2.643 lb)
  • Author
  • Model page created by Karlheinz Fischer. See "Data change" for further contributors.
