New Orleans T-101

• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

• Year
• 1992 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 181831

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• PLL, Phase-locked loop

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: New Orleans T-101 - Grundig Radio-Vertrieb, RVF,

• Shape
• Rack

• Dimensions (WHD)
• 360 x 90 x 300 mm / 14.2 x 3.5 x 11.8 inch

• Notes
• Tuner mit Suchlauf Abstimmung und Senderspeicher.

• Net weight (2.2 lb = 1 kg)
• 2.8 kg / 6 lb 2.7 oz (6.167 lb)

• Literature/Schematics (1)
• Original Grundig Service Unterlagen

• Author
• Model page created by Josef Pilz. See "Data change" for further contributors.
