Ocean Boy 400 G. RF 19
Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Country
- Germany
- Manufacturer / Brand
- Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Year
- 1995–1997 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 292909
-
- alternative name: Grundig Portugal || Grundig USA / Lextronix
Grundig Ocean Boy 400 portable set
Front panel of the set
Details on the back of the receiver
Instruction manual cover page
Operating instructions (German) Page 4
Operating instructions page 8
Operating instructions page 9
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- PLL, Phase-locked loop
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Line / Batteries (any type) / 50-60 Hz, 230-240 / UM-2: 4 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Ocean Boy 400 G. RF 19 - Grundig Radio-Vertrieb, RVF,
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 265 x 135 x 60 mm / 10.4 x 5.3 x 2.4 inch
- Notes
-
Grundig Ocean Boy 400 portable, likely made in Portugal.
- Author
- Model page created by Ian Dublon. See "Data change" for further contributors.
