RC-Generator TG41

• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

• Year
• 1977 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 127506

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Details
• Other Combination - see Notes

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: RC-Generator TG41 - Grundig Radio-Vertrieb, RVF,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 300 x 100 x 170 mm / 11.8 x 3.9 x 6.7 inch

• Notes
• Grundig Sinus-Rechteckgenerator TG41.
  Frequenzbereich 10 Hz...1 MHz, Ausgangsspannung 0,1 mV...6,3 V, 10-dB-Grobteiler mit Feinteiler, Farbskala. Leistungsaufnahme vom Netz 10 Watt.

• Net weight (2.2 lb = 1 kg)
• 3.3 kg / 7 lb 4.3 oz (7.269 lb)

• Mentioned in
• Funkschau (6.1977)

• Author
• Model page created by Karlheinz Fischer. See "Data change" for further contributors.
