Röhrenmessgerät 55A
Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Country
- Germany
- Manufacturer / Brand
- Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Year
- 1960 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 80515
-
- alternative name: Grundig Portugal || Grundig USA / Lextronix
Sammlung: "Das Rundfunkmuseum" in Cham
Sammlung: "Das Rundfunkmuseum" in Cham
Sammlung: "Das Rundfunkmuseum" in Cham
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 12
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Material
- Metal case
- from Radiomuseum.org
- Model: Röhrenmessgerät 55A - Grundig Radio-Vertrieb, RVF,
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 552 x 436 x 325 mm / 21.7 x 17.2 x 12.8 inch
- Notes
- 6x Signallampe 220V, Skalenlampe 7V.
- Net weight (2.2 lb = 1 kg)
- 45 kg / 99 lb 1.9 oz (99.119 lb)
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Bernd Pötzsch. See "Data change" for further contributors.
