RTV350 Ch= CS350

• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

• Year
• 1967–1969

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 27140

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 23

• Semiconductors
• AF106 BF194 BF195 BF185 BC147 BC148 AD161 AD162 BA121 1N60 AA113 AA118 AA119 BYY59 E60C3 B30C250

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz

• Tuned circuits
• 7 AM circuit(s)     13 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110; 130; 220; 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 20 W (max.)

• Material
• Various materials

• from Radiomuseum.org
• Model: RTV350 Ch= CS350 - Grundig Radio-Vertrieb, RVF,

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 550 x 150 x 220 mm / 21.7 x 5.9 x 8.7 inch

• Notes

• Stereo-Steuergerät. Rundfunk-Chassis = CS350; NF-Verstärker mit 2 Endstufen je 10 W.

  Jeder Halbleiter-Typ ist nur einmal gelistet.

• Net weight (2.2 lb = 1 kg)
• 7.8 kg / 17 lb 2.9 oz (17.181 lb)

• Price in first year of sale
• 509.00 DM

• External source of data
• erb

• Source of data
• Handbuch VDRG 1967/1968

• Mentioned in
• Taxliste Franzis Verlag

• Literature/Schematics (1)
• Handbuch für Rundfunk Fernsehen Phono 1967/68 (RFP), Verlag Funk-Kurier, Thiele

• Literature/Schematics (2)
• -- Original-techn. papers.

• Other Models

• Here you find 6208 models, 5434 with images and 4205 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
