RTV350a Ch= CS350a

• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

• Year
• 1968/1969

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 205781

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 23

• Semiconductors
• AF106 BF194 BF195 BF184 BC147 BC148 BC108 AD162 AD161

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110-130; 220-240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Wooden case

• from Radiomuseum.org
• Model: RTV350a Ch= CS350a - Grundig Radio-Vertrieb, RVF,

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 545 x 145 x 225 mm / 21.5 x 5.7 x 8.9 inch

• Notes
• Rundfunk-Chassis = CS350a. Eisenlose Gegentakt-Endstufe 2x 10 W.
  Ausführungen: Nussbaum natur mattiert, Teak natur, Palisander mattiert.

  Transistoren einmal je Type gelistet.

• Net weight (2.2 lb = 1 kg)
• 9.5 kg / 20 lb 14.8 oz (20.925 lb)

• Source of data
• - - Data from my own collection
