• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

• Year
• 1976/1977

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 131233

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 26

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 100; 130; 220; 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Various materials

• from Radiomuseum.org
• Model: RTV850 HiFi 4D - Grundig Radio-Vertrieb, RVF,

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 520 x 140 x 270 mm / 20.5 x 5.5 x 10.6 inch

• Notes
• Wie RTV 820 HiFi aber nur 1 beleuchtetes Anzeigeinstrument für AM-FM-Abstimmanzeige und geänderter Endstufe
  ICs: 4.
  HiFi-Tuner-Verstärker in Pultform mit einer Ausgangsleistung von 2× 16 W (Sinus).

• Source of data
• Handbuch VDRG 1976/1977

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
