RTV500 Ch= RC400

• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

• Year
• 1971–1975

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 28401

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 21

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz

• Tuned circuits
• 7 AM circuit(s)     12 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 8 W (10 W max.)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: RTV500 Ch= RC400 - Grundig Radio-Vertrieb, RVF,

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 592 x 131 x 222 mm / 23.3 x 5.2 x 8.7 inch

• Notes
• Stereo-Steuergerät. NF-Verstärker mit 2 Endstufen je 4 W (Sinus); zwei Lautsprecherboxen (200×130×210 mm) gehören zum Lieferumfang

• Net weight (2.2 lb = 1 kg)
• 5.2 kg / 11 lb 7.3 oz (11.454 lb)

• External source of data
• Erb

• Source of data
• Handbuch VDRG 1971/1972

• Mentioned in
• -- Original prospect or advert (Grundig Revue 1971)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Literature/Schematics (2)
• Antique Radio Magazine - Italy, Club Antique Radio Magazine (n.122, Novembre-Dicembre 2014, pag. 40)

• Other Models

• Here you find 6212 models, 5442 with images and 4209 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
