SO141a Nussbaum
Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Country
- Germany
- Manufacturer / Brand
- Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Year
- 1960/1961
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 23559
-
- alternative name: Grundig Portugal || Grundig USA / Lextronix
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 10
- Main principle
- Superheterodyne (common); ZF/IF 460/10700 kHz
- Tuned circuits
- 8 AM circuit(s) 12 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Details
- Record Player (perh.Changer)
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 220 Volt
- Loudspeaker
- 4 Loudspeakers
- Power out
- 14 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: SO141a [Nussbaum] - Grundig Radio-Vertrieb, RVF,
- Shape
- Console with Push Buttons.
- Dimensions (WHD)
- 1350 x 800 x 440 mm / 53.1 x 31.5 x 17.3 inch
- Notes
- Der Empfänger SO141a hat Gegentakt- Endstufen für NF- Stereofonie mit einer Ausgangsleistung von 2 x 7 Watt und verwendet zwei Halbleiterdioden OA172 im Ratiodetektor.
- Price in first year of sale
- 994.00 DM
- External source of data
- Erb
- Source of data
- HdB d.Rdf-& Ferns-GrH 1960/61
