Sono-Clock (sonoclock) 890
Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Country
- Germany
- Manufacturer / Brand
- Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Year
- 1999 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 75499
-
- alternative name: Grundig Portugal || Grundig USA / Lextronix
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 14
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- FM Broadcast Band Only
- Power type and voltage
- Alternating Current supply (AC) / 230 & back up battery 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
- Power out
- 0.5 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Sono-Clock 890 - Grundig Radio-Vertrieb, RVF,
- Shape
- Tablemodel with Clock ((Alarm-) Clock Radio).
- Dimensions (WHD)
- 276 x 60 x 150 mm / 10.9 x 2.4 x 5.9 inch
- Notes
-
ICs im Radio-Teil: TC926; LA1260; 2201XS1.
Stützbatterie 9V-Block für Uhr- und Weckzeit.
- Net weight (2.2 lb = 1 kg)
- 1.250 kg / 2 lb 12.1 oz (2.753 lb)
- Price in first year of sale
- 79.00 DM
| Grundig Sono Clock 890 Bedienungsanleitung | 487 KB |
- Documents regarding this model
- Author
- Model page created by Bernd Pötzsch. See "Data change" for further contributors.
