SONOCLOCK (sono-clock) 20 Quarz G.KC 04

Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

Data
Forum
Pictures
Collections

  • Year
  • 1992 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 298560
    • alternative name: Grundig Portugal || Grundig USA / Lextronix

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 220-230 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: SONOCLOCK 20 Quarz G.KC 04 - Grundig Radio-Vertrieb, RVF,
  • Shape
  • Tablemodel with Clock ((Alarm-) Clock Radio).
  • Dimensions (WHD)
  • 215 x 46 x 150 mm / 8.5 x 1.8 x 5.9 inch
  • Notes

  • Netzausfallüberbrückung durch 9-V-Stützbatterie.

    Ausführungen:

    • G.KC 04-53R weiss

    Siehe auch Sonoclock 20 ohne Quarz mit Typkennung G.KC 02.

    Made in Malaysia.
