• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

• Year
• 1997 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 250285

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• PLL, Phase-locked loop; ZF/IF 38900 kHz

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 165-265 Volt

• Loudspeaker
• 2 Loudspeakers

• Power out
• 40 W (max.)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: ST70-270 IDTV Ch= CUC1825 - Grundig Radio-Vertrieb, RVF,

• Shape
• Tablemodel, low profile (big size).

• Notes

• Farbfernseher mit 70cm Black Line D Bildröhre.

  100Hz Bildwechselfrequenz,

  99 Programmspeicher+3 AV,

  Hyperband Kabeltuner,

  PAL/SECAM/NTSC 4,43MHz,BG

  Stromaufnahme ca 120W, Standby ca 7W.

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by a member from D. See "Data change" for further contributors.
