• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

• Year
• 1963–1970

• Category
• Radio module post 1925 (not a part, not a key)

• Radiomuseum.org ID
• 26550

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• ECC81

• Number of Transistors
• 1

• Semiconductors
• OC79 OA81 OA180 BA100

• Wave bands
• - without

• Power type and voltage
• Powered by external power supply or a main unit. / AC 6,3 & DC 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Stereo-Automatic-Decoder V - Grundig Radio-Vertrieb, RVF,

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 180 x 80 x 60 mm / 7.1 x 3.1 x 2.4 inch

• Notes

• Dioden: 7× OA81, OA180, BA100.

  Der Grundig Stereo-Decoder V enthält eine pilottongesteuerte Mono-Stereo Umschaltautomatik. Sonst technisch identisch mit Stereo-Decoder IV (ohne Umschaltautomatik).

  In den Handbüchern VDRG und RFP 1963/64 irrtümlich mit 6 Ge-Dioden gelistet.

• Price in first year of sale
• 85.00 DM

• External source of data
• erb

• Source of data
• Handbuch VDRG 1963/1964

• Mentioned in
• Handbuch VDRG 1964/1965

• Literature/Schematics (1)
• Handbuch RFP 1963 (S.202)

• Literature/Schematics (2)
• Grundig Technische Informationen (TI) Aug. 1963, S.570f.

• Literature/Schematics (3)
• -- Original-techn. papers.

• Literature/Schematics (4)
• Funk-Technik (FT) (13/1963, S.463)
