Studio 2220 HiFi

Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

Data
Forum
Pictures
Collections

  • Year
  • 1975–1977
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 131258
    • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 59
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Tuned circuits
  • 6 AM circuit(s)     14 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 130; 220; 240 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • from Radiomuseum.org
  • Model: Studio 2220 HiFi - Grundig Radio-Vertrieb, RVF,
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 670 x 170 x 400 mm / 26.4 x 6.7 x 15.7 inch
  • Notes
  • ICs: 6.
    HiFi-Stereo-Steuergerät für Stereo, 2-Raum-Stereo und 4D-Stereo-Raumklang. Ausgangsleistung: 2× 50 W (Musik) bei Stereo bzw. 4× 20 W (Musik) bei Stereo in 2 getrennten Räumen;
    Phono-Chassis = Dual 1226 mit Magnetsystem Shure M75D.
