Super Color C 8400 Serie F 3026 Ch= CUC70KT
Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Country
- Germany
- Manufacturer / Brand
- Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Year
- 1983
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 131056
-
- alternative name: Grundig Portugal || Grundig USA / Lextronix
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- A66-540X
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 38900 kHz
- Wave bands
- Wave Bands given in the notes.
- Details
- Remote Control (with wire or wireless)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Super Color C 8400 Serie F 3026 Ch= CUC70KT - Grundig Radio-Vertrieb, RVF,
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 710 x 530 x 420 mm / 28 x 20.9 x 16.5 inch
- Notes
- Grundig Super Color C 8400 Serie F 3026 Ch= CUC70KT; 66 cm PAL Farb-TV mit elektronischem VHF/UHF Tuner mit Sonderkanalband nach CCIR B/G. 3,5 mm KH Buchse und DIN AV, IR-FB.
- Net weight (2.2 lb = 1 kg)
- 32.5 kg / 71 lb 9.4 oz (71.586 lb)
- Source of data
- -- Collector info (Sammler)
- Author
- Model page created by a member from A. See "Data change" for further contributors.
