Super Video Recorder SVR 4004 AV

Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

Data
Forum
Pictures
Collections

  • Year
  • 1979 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 199018
    • alternative name: Grundig Portugal || Grundig USA / Lextronix

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Details
  • Video-Taperecorder/-Player
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Super Video Recorder SVR 4004 AV - Grundig Radio-Vertrieb, RVF,
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 590 x 150 x 320 mm / 23.2 x 5.9 x 12.6 inch
  • Notes
  • Video Signal System (Playback): CCIR PAL: [X] SECAM: [_] NTSC: [_] other: [_]
    Video Signal System (Record): CCIR PAL: [X] SECAM: [_] NTSC: [_] other: [_]
    Videostandard: SVR
    Tuner equipped: Yes HF Output: Yes
    Timer: Yes Color: Yes
    Insert-Cut: No Controllable by Editing-System: No
    Output Level: 0.7V RGB Video Output: No
    Composite (FBAS) Video Out: Yes Component Video Output: No
    S-Video Output: No Signal to Noise Video: -
    Horizontal Resol. black/white: 280l. Horizontal Resolution Color: 280l.
    Dropout compensator: Yes Wow and Flutter lin. audiotrack: -
    No. of Audiochannels linear track: 1 No. of Audiochannels helical track:

    0
    Signal to Noise linear Audio track: - Signal to Noise helical Audio track: -
    Symmetrical Audio Out No Non-symmetrical Audio Out Yes












    Audio Frequency Response:-
    Timebase Corrector: No
    Remote Control: Cable



    Grundig SVR 4004 AV;
    PAL Videorecorder, Super Video Recording -System, CCIR B/G elektronik Tuner, 75 W Leistungsaufnahme.

  • Net weight (2.2 lb = 1 kg)
  • 15 kg / 33 lb 0.6 oz (33.04 lb)
  • Price in first year of sale
  • 3,050.00 DM
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
