• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

• Year
• 1969/1970

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 252435

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• PCF802 PCL805 PL509 PY500 A56-120X

• Number of Transistors
• 43

• Semiconductors
• MJE340

• Main principle
• Superheterodyne (common); ZF/IF 38900 kHz

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 2 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: T905 Color Electronic Ch= T902a - Grundig Radio-Vertrieb, RVF,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 690 x 470 x 510 mm / 27.2 x 18.5 x 20.1 inch

• Notes

• Beim Einschalten Ton direkt vorhanden, Bild in ca 40 Sekunden.
  Lautsprecher: 17,2 x 9,6 cm.
  Weitere Bestückung: 2 IC, 65 Halbleiterdioden.
  Leistungsaufnahme: 240 W.
  Zubehör auf Wunsch: Fernbedienung VII color, 44,-DM

  Preis in der Schweiz: 3.460,00 CHF



• Net weight (2.2 lb = 1 kg)
• 38 kg / 83 lb 11.2 oz (83.7 lb)

• Price in first year of sale
• 2,048.00 DM

• Mentioned in
• Grundig Revue 1969-70

• Literature/Schematics (1)
• Handbuch VDRG 1969/1970

• Author
• Model page created by Ernst Moretti. See "Data change" for further contributors.
