FM-AM Quartz Synthesizer Tuner T 7500

• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

• Year
• 1983 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 124167

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 115/220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: FM-AM Quartz Synthesizer Tuner T 7500 - Grundig Radio-Vertrieb, RVF,

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 450 x 80 x 330 mm / 17.7 x 3.1 x 13 inch

• Notes

• Stereoradio mit synthetischer Frequenzaufbereitung, digitaler Frequenzanzeige.

  According to manual: T7500 corresponds in its technical design to the ST6500. Difference: Outward form.

  Made in Portugal

• Net weight (2.2 lb = 1 kg)
• 5.2 kg / 11 lb 7.3 oz (11.454 lb)

• Price in first year of sale
• 850.00 DM

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Werner Ehehalt. See "Data change" for further contributors.
