• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

• Year
• 1964–1966

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 25953

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• DM71

• Number of Transistors
• 8

• Semiconductors
• TF65 TF65 TF65 OC72 OC72 OC74 OC304 AC121 OA71 OA71 OA85

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Batteries / addl. power jack / D: 4 × 1,5 & C: 2 × 1,5 / DC 6 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 0.25 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: TK2 [1964] - Grundig Radio-Vertrieb, RVF,

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 300 x 115 x 175 mm / 11.8 x 4.5 x 6.9 inch

• Notes

• Zweispur; Bandgeschwindigkeit 9,5 cm/s; Spulen-Ø 8 cm. Betrieb aus 6-V-Autobatterie oder separatem Netzanschlußteil (66,- DM) möglich.

• Net weight (2.2 lb = 1 kg)
• 2 kg / 4 lb 6.5 oz (4.405 lb)

• Price in first year of sale
• 279.00 DM

• External source of data
• Erb

• Source of data
• Handbuch VDRG 1964/1965

• Mentioned in
• Handbuch RFP 1964/65

• Literature/Schematics (1)
• -- Original-techn. papers.
