Triumph 300M/H Chassisplatte 074
Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Country
- Germany
- Manufacturer / Brand
- Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Year
- 1970/1971
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 244244
-
- alternative name: Grundig Portugal || Grundig USA / Lextronix
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Details
- Remote Control (with wire or wireless)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Triumph 300M/H Chassisplatte 074 - Grundig Radio-Vertrieb, RVF,
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 670 x 490 x 390 mm / 26.4 x 19.3 x 15.4 inch
- Notes
-
VHF/UHF Allbereichtuner mit Zentralabstimmumung, Kanalanzeige mit Langfeld-Linearskala Anschluß für Fernbedienung II.
- Net weight (2.2 lb = 1 kg)
- 23 kg / 50 lb 10.6 oz (50.661 lb)
- Literature/Schematics (1)
- Grundig Service Unterlagen
- Author
- Model page created by Josef Pilz. See "Data change" for further contributors.
