Twin Cassette Deck CCF5300

• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern

• Year
• 1989

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 199528

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

• Picture
• Schematics

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 71

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Cassette-Recorder or -Player; Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Twin Cassette Deck CCF5300 - Grundig Radio-Vertrieb, RVF,

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 360 x 110 x 290 mm / 14.2 x 4.3 x 11.4 inch

• Notes
• Bandgeschwindigkeit:
  Dubbing: 4,76 cm/sec.
  High dubbing: 9,5 cm/sec.
  Frequenzbereich:
  Cr, Me, Fe: 30 Hz bis 16 kHz.


• Source of data
• -- Original-techn. papers.

• Author
• Model page created by Eduard Abfalterer. See "Data change" for further contributors.
