VCR-3500 AV
Grundig (Radio-Vertrieb, RVF, Radiowerke)
- Country
- Germany
- Manufacturer / Brand
- Grundig (Radio-Vertrieb, RVF, Radiowerke)
- Year
- 1975 ??
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 278264
-
- alternative name: Grundig Portugal || Grundig USA / Lextronix
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Details
- Video-Taperecorder/-Player
- Power type and voltage
- Alternating Current supply (AC)
- Loudspeaker
- - For headphones or amp.
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: VCR-3500 AV - Grundig Radio-Vertrieb, RVF,
- Dimensions (WHD)
- 590 x 151 x 320 mm / 23.2 x 5.9 x 12.6 inch
- Notes
-
Video Signal System (Playback): CCIR PAL: [X] SECAM: [_] NTSC: [_] other: [_] Video Signal System (Record): CCIR PAL: [X] SECAM: [_] NTSC: [_] other: [_] Videostandard: VCR Standard Tuner equipped: Yes HF Output: Yes Timer: Yes Color: Yes Insert-Cut: No Controllable by Editing-System: No Output Level: 0.7V RGB Video Output: No Composite (FBAS) Video Out: Yes Component Video Output: No S-Video Output: No Signal to Noise Video: - Horizontal Resol. black/white: >240l. Horizontal Resolution Color: >240l. Dropout compensator: Yes Wow and Flutter lin. audiotrack: - No. of Audiochannels linear track: 1 No. of Audiochannels helical track: 0
Signal to Noise linear Audio track: - Signal to Noise helical Audio track: - Symmetrical Audio Out No Non-symmetrical Audio Out Yes Audio Frequency Response:-
Timebase Corrector: No
Remote Control: Cable
- Net weight (2.2 lb = 1 kg)
- 15 kg / 33 lb 0.6 oz (33.04 lb)
- Price in first year of sale
- 2,400.00 DM
- Author
- Model page created by Marc Goeritz. See "Data change" for further contributors.
