• Year
  • 1970
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 119018
    • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 10
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 460 kHz
  • Tuned circuits
  • 7 AM circuit(s)     10 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Power type and voltage
  • Dry Batteries / 220 / 9 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Power out
  • 1.5 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Yacht-Boy 210 [1 KW-Bereich] - Grundig Radio-Vertrieb, RVF,
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 380 x 230 x 105 mm / 15 x 9.1 x 4.1 inch
  • Notes
  • Hinweis: Modell ID: 72804 hat 7 KW-Bereiche und ist "Made in Taiwan". Netzteil im Gerät integriert (Type TN 12AU), Externe Spannungsversorgung 9 Volt (Auto/Boot) möglich, Eingang für TB/Plattenspieler über 5 pol Din Buchse, ext. Antenneneingänge (240 Ohm), Skalenbeleuchtung, Instrument für Batt. Kontrolle, Skalenbeleuchtung, Kopfhöreranschluß (Klinke 3,5 mm), 11 tlg. Teleskopantenne (130 cm), Ovallautsprecher (11 x 17,5 cm)
  • Net weight (2.2 lb = 1 kg)
  • 3.8 kg / 8 lb 5.9 oz (8.37 lb)
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Josef Pilz. See "Data change" for further contributors.
