• Country
• United States of America (USA)

• Manufacturer / Brand
• Gulbransen Co.; Chicago

• Year
• 1933 ?

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 43780

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• 78 77 78 75 41 84

• Main principle
• Superhet with RF-stage; ZF/IF 262 kHz

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 6 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• from Radiomuseum.org
• Model: Z6Z1 - Gulbransen Co.; Chicago

• Notes
• Vibrator for +B.

• External source of data
• Ernst Erb

• Circuit diagram reference
• Rider's Perpetual, Volume 4 = ca. 1934 and before

• Other Models

• Here you find 64 models, 10 with images and 31 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Gulbransen Co.; Chicago
