Black Knight RP74MB
Hacker Radio Ltd., Maidenhead
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Hacker Radio Ltd., Maidenhead
- Year
- 1973
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 246656
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 13
- Semiconductors
- BF195 BF195 BF194 BF194 BF194 BF194 BC149 BC149 BC159 AC187 AC188 BC148 T2_tr BZY88 BFY50
- Main principle
- Superheterodyne (common); ZF/IF 10700 kHz; 4 AF stage(s)
- Tuned circuits
- 6 AM circuit(s) 8 FM circuit(s)
- Wave bands
- FM Broadcast Band Only
- Power type and voltage
- Line / Batteries (any type) / 240; 8 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 7 inch = 17.8 cm
- Power out
- 1.5 W (2 W max.)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Black Knight RP74MB - Hacker Radio Ltd., Maidenhead
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 12.8 x 8.1 x 4.3 inch / 325 x 206 x 109 mm
- Notes
-
Equivalent to Black Knight RP74 model, but includes power supply for 240V line in addition to batteries.
